Automatic Roll Tissue Film Wrapping Packaging Machine
High-speed toilet roll wrapping machine, speed 60–120 rolls/min, PLC servo touch control, fast size switch in 10–20 mins, for small & medium toilet tissue factories.(automatic roll tissue packaging machine, toilet paper film wrapping machine, household roll tissue packing machine, tissue roll wrapper)
Product Overview
ST-140B Automatic Roll Tissue Film Wrapping Machine
ST-140B is dedicated automatic film wrapping equipment for toilet roll tissue. It completes film unwinding, fixed-length cutting, suction feeding, clamping, pressing and full wrapping sealing in one continuous workflow. Equipped full PLC + servo motor control with touch screen HMI, the machine features compact layout and easy parameter adjustment. No massive mold replacement needed for different roll sizes; only partial parts adjustment takes 10–20 mins to finish specification switching. Stable running speed up to 120 rolls/min, overload protection ensures long-term safe operation, widely applied for disposable toilet paper, kitchen roll packaging.
Standard Automatic Packaging Workflow
- Plastic film automatic unwinding & fixed-length cutting
- Film suction, clamping and pressing positioning
- Tissue roll automatic feeding into wrapping station
- Full film wrapping & heat sealing
- Finished wrapped toilet rolls auto output
Three Core Product Innovations
High Continuous Production Capacity
Stable maximum speed reaches 120 rolls per minute, meets medium & large volume toilet tissue mass production demands.
Ultra-Fast Size Conversion
Only 10–20 minutes to switch different tissue roll sizes; no large batch molds replacement, just adjust or replace individual spare parts.
Simple PLC Touch Operation
Visual touch screen human-machine interface, intuitive parameter setup, low training cost for new operators.
Main Structural & Functional Advantages
1.Integrated All-in-One Wrapping Structure
Combine film cutting, suction, clamping, pressing and roll wrapping together, compact footprint with neat mechanical layout, easy daily adjustment.
2.Full Servo & PLC Intelligent Control
Servo motor matched with programmable PLC system, all running data displayed on touch screen, high automation level and user-friendly operation.
3.Wide Size Compatibility & Flexible Adjustment
Supports multiple length & diameter toilet rolls within the parameter range, quick switch between various product specifications.
4.Low Changeover Cost
No whole set molds required when changing roll models, only individual component replacement saves mold investment and downtime.
5.Complete Overload Safety Protection
Main drive motor overload auto-stop device prevents mechanical damage, greatly improves long-term operation safety and stability.
Performance Technical Parameter
|
Item/model |
ST-140B |
|
Paper quality of carton |
0.03-0.05mm |
|
Maximum packing specification |
L(90-130)mm,φ100-130mm |
|
Packing speed |
60-120 (rolls/minute) |
|
Motor power |
3.5kw |
|
Total power |
5.7kw |
|
Power supply type |
(3 phase 4 wire) 380V 50Hz |
|
Machine noise |
≤ 80dB |
|
Air supply |
0.5-0.8Mpa |
|
Air consumption |
120-160L/min |
|
Main machine |
L2600 x W2350 x H1650mm |
|
Conveying mechanism |
L155xW180xH1050mm |
|
Machine weight |
3000kg |
Application Scope
Suitable for automatic plastic film wrapping of household roll paper:
- Disposable toilet tissue rolls
- Kitchen absorbent paper rolls
- Small industrial paper rolls within size limit
Packaging & Delivery
The machine is disassembled and packed with export fumigated wooden cases with shockproof foam and moisture-proof film inside, safe for long-distance sea & air transportation. Delivery will be arranged according to signed contract schedule.
